4. Ship specifications

MAIN FEATURES

Displacement: 370 T
Length: 48.9 m
Breadth: 9.0 m
Draught max: 3.8 m
Propulsion: sails 430 m2 raised and driven hydraulically
Auxiliary engine: diesel, 310 HP with controllable pitch propellers, bow thrusters 70 HP
Max speed: 13 knots on sails, 9 knots with engine
Masts: 3, each 32 meters high.
Fuel vol.: 47 tons
Fresh water capacity: 40 tons in the tank
Electrical supply: 135kVA, (three generators: 50, 50 and 35kVA), 400V, 220V, three phases, 50Hz
Stabilised circuit: UPS: 5 kVA, 220V, 50Hz
Hydraulic system: driving sail winches, A-frame and cranes, windlass and other deck machinery

NAVIGATIONAL, COMMUNICATION AND OTHER SUPPORTING EQUIPMENT

Radars: Furuno FR 1505 DA and Furuno 1830
Position fixing: satellite: GPS 8800 Honeywell-Elac and Magnavox 4102 DECCA: Navstar 2000D
Weather information: a receiver for facsimile weather maps: FURUNO FAX 108L
Radio station: SKANTI
Gyro-compass: Wega and automatic steering system PLATH
Echosounders: FURUNO FE 680 and CODEN CVS 822
Log: electromagnetic, 4601 Radmor
Waste disposal: biological treatment plant, incinerator TECHMET
Work boat: inflatable, crew: 6, Yamaha outboard engine
Rescue boat: inflatable, DSB 420 JRB, Yamaha engine

ACCOMMODATION

Cabins: 13 double cabins - 5 m2, 1 cabin for six persons - 10 m2, 1 single cabin - 8 m2 .
Messroom: for 30 persons - 20 m2
Recreation room: with library, TV, VCR, stereo and bar for 20 persons - 20 m2
Air conditioning: central air conditioning and heating system, additionally electrical radiators
Bathrooms: 5 with showers, a laundry with a washing-machine

LABORATORIES

wet laboratory on main deck, 20 m2, isotope laboratory, 4 m2, chemical laboratory, 6 m2, electronic workshop and registration room, 10 m2, computer compartment, 7 m2
